PINACHO SH 400 x 3000
We have a used lathe available immediately:
The machine was in operation for 14 months in single-shift operation!
Siemens 828D control unit with shop turn
Tip height 400 mm
Max. swing diameter 800 mm
Max. machining diameter over slide 510 mm
Center distance 3000 mm
Headstock
Spindle bore 155 mm
Spindle nose front and rear DIN 55026 A2-11
Spindle bearing – inner diameter 190 mm
Speed range I 0 – 288 rpm
Speed range II 288 – 1,000 rpm
Max. torque S1 1527 Nm
Main spindle motor power S1/S6 17 / 21 kW
Automatic revolver
Duplomatic BSV N-200 product
Number of tool stations: 8
Tool holders according to VDI 40
Includes the following accessories:
Spindle bore 155 mm
Coolant system with 20 bar high-pressure pump for drilling and deep boring work
Chip conveyor with gooseneck discharge, height 970 mm
Moving bezel with 3 roller stands, Ø 70 – 290 mm
Closed, split bezel with 3 roller positions, 90 – 300 mm
Closed, split bezel with 3 roller positions, 300 – 530 mm
3-jaw chuck with Ø 400 mm on the back of the spindle housing
4-jaw faceplate Ø 500 mm
Forkardt F+400 wedge bar chuck with bore Ø 130 mm
