MT Evo UDS80H-5A

Max. table load: 1,300 kg

Spindle speed: 18,000 rpm – Torque: 187 Nm (40%) – Power: 39 kW (40%)
Currently 3,410 spindle hours

Rapid traverse: X/Y/Z 48 m/min

Feed rate: 1-20,000 mm/min

o Positioning accuracy of linear axis: 0.010 mm

o Repeatability linear ash: 0.006mm

Positioning accuracy of rotary axis: A-axis 10° / C-axis 10°

o Tool holder: HSK-A63

Tool changer: 96 places

o Changeover time (tool to tool): 3 sec.

Max. tool weight: 7 kg

Machine weight: 18,600 kg

o Tool measurement: Blum laser
